Pos.
Part                   -
Description
Eur    -
38a
M60600015
MECH.SEAL SPACER WASHER D.26x14,5x1 INOX
11
5b
M72527152A
LOW. HAB NORYL IMPELLER ULTRA 5
15
1
S70017058
SUC./DEL  S.STEEL BODY  ULTRA 5-7L
131
2
S70036002
BRACKET ULTRA L MEC80
64
4
S75405431C
ALB.+ROT. D.65 H100T U 5/6T IE3
1
5
M72527152
NORYL IMPELLER ULTRA 5
15
7
M72519031
SUCT. NORYL DIFF. (3/5/7)ULTRA(NO USE)-C
15
8
M72519032
PRE. NORYL DIFF.ULTRA 3/5/7(NO USE)-C
28
10
M72519030
NORYL DIFFUSER ULTRA 3/5/7 (NO USE)-C
12
13
M60400046
MECH. SEAL PFC 26x14x7,5 V1E-VTC (EPDM)
13
13
M60400045
MECH. SEAL PR/AR 14S B2EGG (EPDM)
19
14
S57900557
CAS+ST.125x65-100T 230/400-50 IE3
350
15
S70214027
COPERCHIO MOTORE MEC80 (D.40)
13
16
M60100015
VENTOLA MEC90/80 IE3 12 PALE D.16,8
11
17
M60200022
FAN COVER MEC80
36
18
M61100003
TERMINAL BLOCK  BAM4 6M 50x32 M4 3PH
16
20
M72606003
SPLASH GUARD D.15
9
21/137
M60513006
IMPELLER STOP NUT M8-8 UNI 5588 A/2 INOX
11
22/23
M60300014
BEARING  6203-ZZ D NS7SJ
16
22
M60300020
BEARING  6304-ZZ C3 EA3SW
21
24
M60603014
ANELLO COMPENSATORE 40 B (6203)
11
25
M75450020
TIRANTE ZINCATO M5x180
12
25/47
M75450006
ROD     M 8x242 MEC 132 S
15
28/29
M75147003
PLUG 3/8    BRASS
18
29
M75147004
PLUG 3/8    BRASS
24
31
M60900061
OR GASKET 138,90x3,75
15
33
M60900036
VENTURI TUBE O-RING 39,34x2,62 AP 2
11
33/51/53
M60900044
O-RING GASKET 52,39x3,53
17
43
M62100007
BLEED VALVE 1/8
15
49
M71401043
STAINLESS STEEL TUBE ULTRA 5/7-6
35
50/52
S70013009A
FLANGE  ULTRA 1  1/4
21
72
S70011005
FLANGE P.TENUTA U L
47
93
M60602011
BLOCKING HALF RINGS ULTRA
11
94
M60601011
IMPELLER SHOULDER WASHER ULTRA3/5/7 H=6
9
97
S70003020
BASE APPOGGIO U 5/7L
64

These parts are interchangeable with PENTAX and MARLEY
